ESV

Power:  Single 24-volt magnet DC 1000-watt motor

Transmission:  direct drive through 30:1 reduction gearbox

Speed Control:  smooth, foot-operated accelerator pedal

Directional Control:  Forward/Reverse switch conveniently located on main control

Max Speed:  8 to 10 mph in consideration of terrain

Hill Climbing ability:  1:3 gradient

Battery charging: on board permanent charger

Frame:  MIG welded high tensile steel with corrosion protection

Brakes:  single regenerative electromagnetic braking

Batteries:  Two heavy duty sealed 12 volt 85 amp/hour, in series

Battery Charger:  10 amp automatic cut off when fully charged

Tires:  13" x 6.50 x 6" tubeless

Overall length:  50" including utility box

Overall width:  32" including utility box

Overall height:  28" when folded down

Weight:  303 lbs

Load Capacity:  600 lbs

Runtime:  Approximately 30 miles
